Model.A2D300-AD20-02-49
Motor:M2D068-EC
Type Axial Fan
Nominal voltage:230/400VAC
Frequency : 50/60Hz
Valid for approval/standard:CE Speed:2650/2950RPM
Power consumption:220/320W
Current draw:0.22/0.26A
Air flow:1905m³/h Weight:2.8kg
Size:300mm
Motor Size:68 Rotor surface:Painted black Blade material:Sheet steel.painted black Number of blades:5
Airflow direction:A
Degree of protection:IP44
Insulation class:F
Motor bearing:Ball bearing
Min. ambient temperature / °C~Max. ambient temperature / °C:-25℃~50℃ Package:
